Omron FQ2-S Series User Manual

Command Control
392
FQ2-S/CH User’s Manual
for Communications Settings
● Set Communication Input Status: 280F 00307010
This command sets the input status (allowed/prohibited) of the communications port for the specified
communications protocol.
Communications protocols with the input status set to prohibited will no longer receive communications after
being set as such.
However, for inputs related to hardware (parallel TRIG signal and DSA signal), this setting is not applicable.
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Communications protocol type to
be set (4 bytes)
Setting value (4 bytes)
28 0F 00307010 Communications protocol type to
be set (1 digit max.)
Communications protocol status
to be set (1 digit max.)
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00307010
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Communications proto-
col type to be set
Specifies the type of communications protocol to be set.
0: No protocol (TCP, UDP, FINS)
1: No protocol (RS-232C)
2: Parallel I/O
3: Fieldbus
5: PLC link
Setting value Sets the status of the communications protocol.
0: Input prohibited status
1: Input allowed status
FQ2-S_CH_comm.book 392 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
