Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
415
5
Appendices
● Load All Setting Data: 280F 00605000
This command loads all setting data (all scene data, system data, calibration group data) for the Sensor saved
as a backup file from the SD card inserted in the Touch Finder.
The source for backup files is the following fixed directory on the SD card.
\Sensor name\BKD
Format
Response Format
End Codes
Parameter Descriptions
Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
All setting data backup file name
(4 to 64 bytes)
28 0F 00605000 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00605000
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
All setting data backup
file name
Specifies the all configuration data backup file name to be loaded.
The file name extension (.bkd) can be omitted.
Important
FQ2-S_CH_comm.book 415 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
