Command Control
414
FQ2-S/CH User’s Manual
for Communications Settings
● Load System Data: 280F 00603000
This command loads system data that is stored on the SD card inserted in the Touch Finder.
The source for system data is the following fixed directory on the SD card.
\Sensor name\SYD
Format
Response Format
End Codes
Parameter Descriptions
Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
System data file name
(4 to 64 bytes)
28 0F 00603000 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00603000
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
System data file name Specifies the system data file name to be loaded.
The file name extension (.syd) can be omitted.
Important
