Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
413
5
Appendices
● Load All Scene Data: 280F 00602000
Loads all scene data that is stored on the SD card inserted in the Touch Finder.
The source for all scene data is the following fixed directory on the SD card.
\Sensor name\SGP
Format
Response Format
End Codes
Parameter Descriptions
Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Scene group number (4 bytes) Scene group data file
name (4 to 64 bytes)
28 0F 00602000 2 digits max. 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00602000
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Scene group data file
name
(all scene data file name)
Specifies the all scene data file name to be loaded.
The file name extension (.sgp) can be omitted.
Specifies the scene group number (0 to 31) to be loaded.
Important
