Command Control
412
FQ2-S/CH User’s Manual
for Communications Settings
Load Setting Data Commands
● Load Scene Data: 280F 00601000
Loads scene data that is stored on the SD card inserted in the Touch Finder.
The source for scene data is the following fixed directory on the SD card.
\Sensor name\SCN
Format
Response Format
End Codes
Parameter Descriptions
Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Scene number (4 bytes) Scene data file name
(4 to 64 bytes)
28 0F 00601000 2 digits max. 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00601000
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Scene number Specifies the scene number (0 to 31) to be loaded
Scene data file name Specifies the scene data file name you want to load.
Only files with the extension "SCN" can be loaded.
Important
