Command Control
FQ2-S/CH User’s Manual
for Communications Settings
411
5
Appendices
● Set Terminal Offset Data: 280F 00504060
This command sets the value of the terminal offset data that is added to the IN0 to IN4 command parameters
when executing parallel commands.
When using parallel command scene changing, you can change the scenes to change to by changing the Set
Terminal Offset Data value.
Command Format
Response Format
End Codes
Parameter Descriptions
When using the Sensor in Expanded Mode while using the standard parallel interface of the Sensor, the range of
scene numbers that can be changed to with scene changing is limited to 0 through 15. By offsetting the command
parameter with this command, the scene can be changed to scene number 0 through 31.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Terminal offset value (4 bytes)
28 0F 00504060 2 digits max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00504060
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Terminal offset value Specifies the value to be added to the IN0 to IN4 command parameters when executing parallel com-
mands.
Note
