Command Control
416
FQ2-S/CH User’s Manual
for Communications Settings
● Load Calibration Data: 280F 0060A000
This command loads calibration data that is stored on the SD card inserted in the Touch Finder as the
calibration data with the specified number.
The source for calibration data is the following fixed directory on the SD card.
\Sensor name\CLB
Format
Response Format
End Codes
Parameter Descriptions
Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Calibration
number
(4 bytes)
Calibration data file name
(4 to 64 bytes)
28 0F 0060A000 2 digits max. 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 0060A000
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Calibration number Specifies the calibration number you want to load. (0 to 31)
Calibration data file
name
Specifies the calibration data file name you want to load.
The file name extension (.clb) can be omitted.
Important
