Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
421
5
Appendices
● Save Scene Group Data: 280F 00702000
This command saves all scene data as a file to the SD card inserted in the Touch Finder.
The destination for all scene data is the following fixed directory on the SD card.
\Sensor name\SGP
Format
Response Format
End Codes
Parameter Descriptions
• If the specified file name already exists, this existing file will be overwritten.
• Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Save scene group number
(4 bytes)
All scene data file
name (4 to 64 bytes)
28 0F 00702000 2 digits max. 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00702000
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
All scene data file name Specifies the all scene data file name to save.
The file name extension (.sgp) can be omitted.
Important
