Omron FQ2-S Series User Manual

Command Control
420
FQ2-S/CH User’s Manual
for Communications Settings
Save Configuration Data Commands
● Save Scene Data: 280F 00701000
This command saves scene data to the SD card inserted in the Touch Finder as a file.
The destination for scene data is the following fixed directory on the SD card.
\Sensor name\SCN
Format
Response Format
End Codes
Parameter Descriptions
• If the specified file name already exists, this existing file will be overwritten.
• Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Save scene number (4 bytes) Scene data file name
(4 to 64 bytes)
28 0F 00701000 2 digits max. 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00701000
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Scene number Specifies the scene number (0 to 31) to be saved.
Scene data file name Specifies the file name when saving.
The file name extension (.scn) can be omitted.
Important
FQ2-S_CH_comm.book 420 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
