Omron FQ2-S Series - Page 421

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
419
5
Appendices
● Load All Model Dictionary Data: 280F 0060D000
This command loads all model dictionary data that is stored on the SD card inserted in the Touch Finder.
The source for all model dictionary data is the following fixed directory on the SD card.
\Sensor name\DGP
Format
Response Format
End Codes
Parameter Descriptions
Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
All model dictionary data file
name (4 to 64 bytes)
28 0F 0060D000 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 0060D000
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
All model dictionary data
file name
Specifies the all model dictionary data file name to be saved.
The file name extension (.dgp) can be omitted.
Important
