Command Control
418
FQ2-S/CH User’s Manual
for Communications Settings
● Load Model Dictionary Number Data: 280F 0060C000
This command loads model dictionary data that is stored on the SD card inserted in the Touch Finder as the
specified model dictionary number.
The source for calibration data is the following fixed directory on the SD card.
\Sensor name\DIC
Format
Response Format
End Codes
Parameter Descriptions
Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Model dictio-
nary number
(4 bytes)
Model dictionary data file
name (4 to 64 bytes)
28 0F 0060C000 2 digits max. 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 0060C000
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Model dictionary number Specifies the model dictionary number you want to load. (0 to 31)
Model dictionary data file
name
Specifies the model dictionary data file name you want to load.
The file name extension (.dic) can be omitted.
Important
