Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
423
5
Appendices
● Save Image Data: 280F 00704000
Saves image data saved in the Sensor's memory by the logging function to the SD card inserted in the Touch
Finder as ifz data.
The destination for image data is the following fixed directory on the SD card.
\Sensor name\LOGIMAGE\Number*
*Number is a five digit number starting from 00000. The images are saved in increments of 100 images for each number, and when there
are over 100 images, the directory with the next number is created.
Format
Response Format
End Codes
Parameter Descriptions
• If the same file is specified as an existing file, the existing file will be overwritten.
• Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Image data file name
(4 to 64 bytes)
28 0F 00704000 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00704000
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Image data number Specifies the number of the image data to be saved.
The maximum number of logged images is 20 (image data number: 0 to 19).
The image data number of the latest image is 0.
Image data file name Specifies the image data file name when saving. (64 characters max.)
The file name extension (.ifz) can be omitted.
Important
