Command Control
424
FQ2-S/CH User’s Manual
for Communications Settings
● Save All Image Data: 280F 00704010
This command saves all image data saved in the Sensor's memory by the logging function to the SD card
inserted in the Touch Finder as ifz data.
The destination for logging image data is the following fixed directory on the SD card.
\Sensor name\LOGIMAGE\Number
*
*Number is a five digit number starting from 00000. The images are saved in increments of 100 images for each number, and when there
are over 100 images, the directory with the next number is created.
Format
Response Format
End Codes
Image Data File Names
Image data file names are automatically created as follows.
img_ScnNNN_YYYY_MM_DD-HH_mm_ss(S)_TTTT_XX.ifz
*1 The date and time are not recorded in the image data. Therefore, this is not the date and time that the measurement was performed, this is
the date and time the image data file was saved from the Sensor to the Touch Finder SD card by this command.
For example, when performing the 10th measurement with scene 1 after the Sensor's power supply has been turned on, and the execution
time of this command is December 5, 2013, at 22:10:21
img_Scn001_2013_12_05-22_01_21(1)_0010_OK.ifz
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F 00704010
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00704010
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
img Prefix string. The string can be set as desired with the following setting.
(Setup Mode or Run Mode) − [TF settings] − [File format]
ScnNNN Scn + measured scene number (0 to 31)
YYYY_MM_DD Date that the image data was saved to the Touch Finder SD card
*1
HH_mm_ss Time that the image data was saved to the Touch Finder SD card
*1
(S) Image data number (0 to 19)
Image data number of the latest image is 0.
TTTT Number of measurements since the Sensor was started. Reset when the power supply is
turned OFF. (0000 to 9999)
XX Total judgment (OK/NG)
