Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
425
5
Appendices
● Save All Setting Data: 280F 00705000
This command saves all setting data (all scene data, system data, calibration group data) for the Sensor to the
SD card inserted in the Touch Finder as a backup file.
The destination for backup data is the following fixed directory on the SD card.
\Sensor name\BKD
Format
Response Format
End Codes
Parameter Descriptions
Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
All setting data file name
(4 to 64 byte)
28 0F 00705000 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00705000
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
All setting data file name This command specifies the all setting data backup file name.
The file name extension (.bkd) can be omitted.
Important
