Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
397
5
Appendices
● Batch Set D Terminal Statuses: 280F 00308030
Batch sets the ON/OFF status for the D terminals (D0 to D15).
Before executing this command, change the FQ2 execution mode to stop mode with the Set Execution Mode com-
mand.
Set Execution Mode: p.398
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Terminal status (4 bytes)
28 0F 00308030 5 digits max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00308030
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Terminal status Specifies the ON/OFF status for the terminal. (ON: 1, OFF: 0) (0 to 65,535)
BIT0: D0
BIT1: D1
BIT2: D2
BIT3: D3
BIT4: D4
BIT5: D5
BIT6: D6
BIT7: D7
BIT8: D8
BIT9: D9
BIT10: D10
BIT11: D11
BIT12: D12
BIT13: D13
BIT14: D14
BIT15: D15
Important
FQ2-S_CH_comm.book 397 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
