Command Control
394
FQ2-S/CH User’s Manual
for Communications Settings
● Set Terminal Status: 280F 00308010
This command sets the output signal ON/OFF status for the specified parallel I/O terminal.
Command Format
Response Format
End Codes
When turning the parallel terminals ON or OFF with this command, there are terminals that cannot be controlled if
the FQ2 execution mode is not set to stop mode.
In this case, first change the FQ2 execution mode to stop mode with the Set Execution Mode command, and then
execute this command.
Set Execution Mode: p.398
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Terminal type (4 bytes) Te r m i n a l n um ber
(4 bytes)
Terminal status
(4 bytes)
28 0F 00308010 2 digits max. 1 digit max. 1 digit max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00308010
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Note
