FQ2-S/CH User’s Manual
for Communications Settings
201
5
Appendices
Command (PLC to Sensor Controller)
Specifying Real Numbers
Specify 1,000 times the actual value to specify a real number.
In this input example, the lower limit (external reference number 137) of the measurement coordinate X of the
Search registered in Unit No. 1 is set to "123.4" in the inspection item data setting command.
Command (PLC to Sensor Controller)
First word in
Command Area
Hexadeci-
mal notation
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 4000 0100 0000 0000 0000 Command code
+3 0070 0000 0000 0111 0000
+4 0001 0000 0000 0000 0001 Image data No.
+5 0000 0000 0000 0000 0000
+6 4D49 0100 1101 0100 1001 File Name (IMAGENAME.IFZ)
+6: MI(4D49)
+7: GA(4741)
+8: NE(4E45)
+9: MA(4D41)
+10: .E(2E45)
+11: FI(4649)
+12: Z(005A)
+13:
+7 4741 0100 0111 0100 0001
+8 4E45 0100 1110 0100 0101
+9 4D41 0100 1101 0100 0001
+10 2E45 0010 1110 0100 0101
+11 4649 0100 0110 0100 1001
+12 005A 0000 0000 0101 1010
+13 0000 0000 0000 0000 0000
First word in Command Area Description
+2 and +3 words Command code (1020 0050 hex)
+4 and +5 words Unit number 1 (0000 0001 hex)
+6 and +7 words External reference number 137 (0000 0089 hex)
+8 and +9 words Lower limit of measurement coordinate X: 123.4 (x 1,000: 123400 = 0001
E208 hex)
First word in
Command Area
Hexadeci-
mal notation
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1020 0001 0000 0010 0000 Command code
+3 0050 0000 0000 0101 0000
+4 0001 0000 0000 0000 0001 Unit No.
+5 0000 0000 0000 0000 0000
+6 0089 0000 0000 1000 1001 External reference number
+7 0000 0000 0000 0000 0000
+8 E208 1110 0010 0000 1000 Lower limit value of measure-
ment coordinate X
+9 0001 0000 0000 0000 0001
