Omron FQ2-S Series User Manual

Controlling Operation and Outputting Data with PLC Link Communications
132
FQ2-S/CH User’s Manual
for Communications Settings
Command Tables for PLC Link Communications
This section describes the commands used in PLC Link communications.
● Execution Commands
Signal Signal name Function Application
DATA0-255 Output data 0 to 255 These I/O ports output the output data that is
specified for the data output method.
The range of the data that can be output is
determined by the set value of the [Max output
data] (number of output data upper value)
parameter setting as follows:
Minimum setting (32 bytes): Output data 0 to 7
Default setting (256 bytes): Output data 0 to 63
Maximum setting (1,024 bytes): Output data 0
to 255
Data output after
measurements
If the size of data that is output exceeds the set value of the number of output data upper value setting, the remain-
ing data will be discarded.
Order of Output of Measurement Data and Characters: p. 24
First word of com-
mand area (hex)
Command name Function Reference
+2 +3
1010 0010 Single Measurement Executes one measurement. p.207
1020 0010 Start Continuous Measure-
ments
Starts continuous measurements. p.207
1030 0010 End Continuous Measure-
ments
Ends continuous measurements. p.208
2010 0010 Clear Measurement Values Clears the measurement values. p.208
2060 0010 Clear Statistical Data Clears the statistical data (such as the num-
ber of measurements, the number of NG
overall judgments, the NG rate, and other
information since the power supply was
turned ON) produced by the logging function
held by the Sensor.
p.209
3010 0010 Save Data in Sensor Saves the current system data and all scene
data in the Sensor.
p.210
4010 0010 Re-register Model (Search,
Shape search II, Sensitive
search, Color data)
Re-registers the reference values for all regis-
tered inspection items based on the previ-
ously loaded image.
p.210
4020 0010 Teaching (All Inspection Items) Executes teaching for all registered inspec-
tion items.
p.211
Note
