Controlling Operation and Outputting Data with PLC Link Communications
FQ2-S/CH User’s Manual
for Communications Settings
133
3
Controlling Operation and Outputting Data with an
Ethernet Connection
Commands to Get Status
Commands to Set Status
Commands to Read Data
4021 0010 Teaching (Filter/Position Com-
pensation Item)
Updates reference data for the specified
image adjustment processing item (filter item/
position compensation item).
p.211
4022 0010 Teaching (Inspection Item) Updates the reference data for the specified
inspection item.
p.212
4031 0010 Re-register Reference Value
(Position Compensation Item)
Re-registers the reference value for the spec-
ified position compensation item based on
the previously loaded image.
p.212
4032 0010 Re-register Reference Value
(Inspection Item)
Re-registers the reference values for the
specified inspection item based on the previ-
ously loaded image.
p.213
8010 0010 Set Registered Image Sets the latest image or a specified logging
image as a registered image.
p.213
8020 0010 Acquire Registered Image Loads a registered image saved to the SD
card or PC Tool as the measurement image.
p.214
9010 0010 Echo This command returns any data (32 bits or 2
words) sent by the external device as-is.
p.215
F010 0010 Reset Vision Sensor Restarts the Sensor. p.215
First word of com-
mand area (hex)
Command name Function Reference
+2 +3
1000 0020 Get Scene Number Aquires the scene number currently being
used.
p.216
First word of com-
mand area (hex)
Command name Function Reference
+2 +3
1000 0030 Select Scene Changes the scene number to be used. p.216
First word of com-
mand area (hex)
Command name Function Reference
+2 +3
1010 0040 Get Image Adjustment Item
Data
Acquires parameters and measurement val-
ues for a position compensation item or filter
item.
p.217
1020 0040 Get Inspection Item Data Acquires parameters and measurement val-
ues for the specified inspection item.
p.218
First word of com-
mand area (hex)
Command name Function Reference
+2 +3
FQ2-S_CH_comm.book 133 ペー 01年626 木日 前1時4
