Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
213
5
Appendices
Response (Vision Sensor to PLC)
Re-register Reference Value (Inspection Item)
This command re-registers the reference values for the specified inspection item based on the previously
loaded image.
Command (PLC to Vision Sensor)
* Only "0" can be specified with the FQ2-S1 series.
Response (Vision Sensor to PLC)
Set Registered Image
Sets the latest image or a specified logging image as a registered image.
Registered images are saved to the following directory on the SD card or PC Tool.
\Sensor name\REGIMAGE
*
The file name is not case sensitive. The file name extension can be omitted.
The image specified as a registered image can be loaded as a measurement image with the Acquire
Registered Image command.
Acquire Registered Image: p.214
A maximum of 1000 registered images (image registration number: 0 to 999) can be set.
* For the PC Tool, the data is saved in the "\..\My Documents\OMRON FQ\" folder.
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0100 0000 0011 0001 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0001 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
First word of com-
mand area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0100 0000 0011 0010 Command code
+3 0000 0000 0001 0000
+4 0000 0000 0000 0000 Inspection item number (0 to 31)
*
+5 0000 0000 0000 0000
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0100 0000 0011 0010 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0001 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
FQ2-S_CH_comm.book 213 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
