Omron FQ2-S Series User Manual

Command Control
214
FQ2-S/CH User’s Manual
for Communications Settings
Command (PLC to Vision Sensor)
* Only when setting the Sensor's logging images as registered images
Response (Vision Sensor to PLC)
Acquire Registered Image
This command loads a registered image saved to the SD card or PC Tool as the measurement image.
The registered image is the latest image or a logging image that has been assigned a number between 0 and
999 and has been registered in advance with the Set Registered Image command.
Set Registered Image: p.213
Command (PLC to Vision Sensor)
First word of com-
mand area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1000 0000 0001 0000 Command code
+3 0000 0000 0001 0000
+4 0000 0000 0000 0000 Registered image number (0 to 999)
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Specifying the image to set as a registered
0: Latest measurement image
1: Sensor logging image
+7 0000 0000 0000 0000
+8 0000 0000 0000 0000 Logging image number (0 to 19)
*
+9 0000 0000 0000 0000
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1000 0000 0001 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0001 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
First word of com-
mand area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1000 0000 0010 0000 Command code
+3 0000 0000 0001 0000
+4 0000 0000 0000 0000 Registered image number (0 to 999)
+5 0000 0000 0000 0000
