Response (Vision Sensor to PLC)
Acquire Image Adjustment Item Data
This command acquires parameters and measurement values for a position compensation item or filter item.
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
First word of
response area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0000 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0011 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
First word of com-
mand area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0001 0000 Command code
+3 0000 0000 0100 0000
+4 0000 0000 0000 0000 Position compensation item/filter item number
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Data number
9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series
User's Manual (Cat. No. Z337)
+7 0000 0000 0000 0000
First word of
response area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0001 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0100 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Acquired data
(1,000 times the value)
+7 0000 0000 0000 0000
