Omron FQ2-S Series User Manual

Command Control
210
FQ2-S/CH User’s Manual
for Communications Settings
Response (Vision Sensor to PLC)
Save Data in Sensor
This command saves the current system data and scene group to the Sensor.
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
Re-register Model (Search, Shape search II, Sensitive search, Color data)
This command re-registers the reference values for the registered inspection items based on the previously
loaded image.
Command (PLC to Vision Sensor)
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0010 0000 0110 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0001 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
First word of com-
mand area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0011 0000 0001 0000 Command code
+3 0000 0000 0001 0000
First word of
response area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0011 0000 0001 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0001 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
First word of com-
mand area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0100 0000 0001 0000 Command code
+3 0000 0000 0001 0000
FQ2-S_CH_comm.book 210 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
