Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
203
5
Appendices
Commands to Get Status
Commands to Set Status
Commands to Read Data
OK: Applicable command, RST: Command with restricted execution, NA: Non-applicable command
Function Parallel
p. 46, p. 75
PLC link
p. 133
EtherNet/
IP
p. 110
PROFINET
p. 157
No-proto-
col (TCP/
UDP/RS-
232C)
p. 178
No-proto-
col (FINS)
p. 192
Aquires the scene number currently being used. NA OK OK OK OK OK
OK: Applicable command, RST: Command with restricted execution, NA: Non-applicable command
Function Parallel
p. 46, p. 75
PLC link
p. 133
EtherNet/
IP
p. 111
PROFINET
p. 157
No-proto-
col (TCP/
UDP/RS-
232C)
p. 178
No-proto-
col (FINS)
p. 193
Changes the scene number to be used. OK OK OK OK OK OK
OK: Applicable command, RST: Command with restricted execution, NA: Non-applicable command
Function Parallel
p. 46, p. 75
PLC link
p. 133
EtherNet/
IP
p. 111
PROFINET
p. 158
No-proto-
col (TCP/
UDP/RS-
232C)
p. 178
No-proto-
col (FINS)
p. 192
Acquires the list of registered dictionary data numbers. NA NA NA NA OK NA
Acquires parameters and measurement values for a
position compensation item or filter item.
NA OK OK OK OK OK
Acquires parameters and measurement values for the
specified inspection item.
NA OK OK OK OK OK
Acquires the text string data of the specified inspection
item.
NA NA NA NA OK NA
Acquires the value of the specified camera parameter. NA OK OK OK OK OK
Acquires the parameters for the measurement region or
model registration region set for an inspection item.
NA NA NA NA OK NA
Acquires the parameters for the measurement region or
the model registration region set for an image adjust-
ment item (filter item/position compensation item).
NA NA NA NA OK NA
Acquires the specified dictionary data cutout region
parameters.
NA NA NA NA OK NA
Acquires the Sensor's software version. NA OK OK OK OK OK
Acquires the version information of the Sensor hard-
ware.
NA NA NA NA OK NA
Acquires the value set for the specified system data. NA OK OK OK OK OK
Acquires the terminal offset data that is added to the
IN0 to IN4 command parameters when executing paral-
lel commands.
NA OK OK OK OK OK
Acquires the statistical data (such as the number of
measurements, number of NG overall judgments, and
other information, since the power supply was turned
ON) held by the Sensor.
NA OK OK OK OK OK
Acquires the Sensor's most recent error code. NA OK OK OK OK OK
