Controlling Operation and Outputting Data with EtherNet/IP Communications
FQ2-S/CH User’s Manual
for Communications Settings
111
3
Controlling Operation and Outputting Data with an
Ethernet Connection
● Commands to Set Status
● Commands to Read Data
Command code in
command area (hex)
Command name Function Reference
+2 +3
1000 0030 Select Scene Changes the scene number to be used. p.216
Command code in
command area (hex)
Command name Function Reference
+2 +3
1010 0040 Get Image Adjustment Item
Data
Acquires parameters and measurement val-
ues for a position compensation item or filter
item.
p.217
1020 0040 Get Inspection Item Data Acquires parameters and measurement val-
ues for the specified inspection item.
p.218
1040 0040 Acquire Camera Parameter Acquires the value of the specified camera
parameter.
p.218
3000 0040 Get Software Version Informa-
tion
Acquires the Sensor's software version. p.221
4010 0040 Acquire System Data Acquires the value set for the specified sys-
tem data.
p.222
4060 0040 Acquire Terminal Offset Data Acquires the terminal offset data that is
added to the IN0 to IN4 command parame-
ters when executing parallel commands.
p.226
6010 0040 Acquire Statistical Data Acquires the statistical data (such as the
number of measurements, number of NG
overall judgments, and other information,
since the power supply was turned ON) held
by the Sensor.
p.227
5000 0020 Get Latest Error Information Acquires the Sensor's most recent error
code.
p.227
7010 0020 Acquire Communication Input
Status
Acquires the input status (allowed/prohib-
ited) for the communications protocol set with
the Set Communication Input Status com-
mand.
p.228
7020 0020 Acquire Communication Out-
put Status
Acquires the output status (allowed/prohib-
ited) for the communications protocol set with
the Set Communication Output Status com-
mand.
p.229
8010 0020 Acquire Terminal Status Acquires the ON/OFF status of the input sig-
nal for the specified parallel I/O terminal.
p.230
8020 0020 Batch Acquire Terminal Status Batch acquires the ON/OFF status for the all
parallel I/O input terminals other than the IN
terminals.
p.231
8030 0020 Batch Acquire IN Terminal Sta-
tus
Batch acquires the ON/OFF status for the IN
terminals.
p.231
F000 0020 Acquire Execution Mode Acquires the FQ2 execution status (execution
mode).
p.232
