Omron FQ2-S Series User Manual

Controlling Operation and Outputting Data with EtherNet/IP Communications
112
FQ2-S/CH User’s Manual
for Communications Settings
● Commands to Write Data
● Load Setting Data Commands
Command code in
command area (hex)
Command name Function Reference
+2 +3
1010 0050 Set Image Adjustment Item
Data
Sets parameters for a position compensation
item or filter item.
p.233
1020 0050 Set Inspection Item Data Sets parameters for the specified inspection
item.
p.233
1040 0050 Set Camera Parameter Sets the value for the specified camera
parameter.
p.234
4010 0050 Set System Data Sets the value to the specified system data. p.235
4060 0050 Set Terminal Offset Data Sets the value of the terminal offset data that
is added to the IN0 to IN4 command parame-
ters
p.235
7010 0030 Set Communication Input Sta-
tus
Sets the input status (allowed/prohibited) of
the communications port for the specified
communications protocol.
p.236
7020 0030 Set Communication Output
Status
Sets the output status (allowed/prohibited) of
the communications port for the specified
communications protocol.
p.237
8010 0030 Set Terminal Status Sets the output signal ON/OFF status for the
specified parallel I/O terminal.
p.238
8020 0030 Batch Set Terminal Status Batch sets the ON/OFF status for the all par-
allel I/O output terminals other than the D ter-
minals (D0 to D15).
p.239
8030 0030 Batch Set D Terminal Status Batch sets the ON/OFF status for the D termi-
nals (D0 to D15).
p.240
F000 0020 Set Execution Mode Sets the FQ2 execution status (execution
mode).
p.241
Command code in
command area (hex)
Command name Function Reference
+2 +3
1000 0060 Load Scene Data Loads scene data that is stored on the SD
card inserted in the Touch Finder.
p.242
2000 0060 Load All Scene Data Loads all scene data that is stored on the SD
card inserted in the Touch Finder.
p.243
3000 0060 Load System Data Loads system data that is stored on the SD
card inserted in the Touch Finder.
p.244
5000 0060 Load All Setting Data Loads all setting data (all scene data, system
data, calibration group data) for the Sensor
saved as a backup file from the SD card
inserted in the Touch Finder.
p.245
A000 0060 Load Calibration Data Loads calibration data that is stored on the
SD card inserted in the Touch Finder as the
specified calibration number.
p.246
FQ2-S_CH_comm.book 112 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
