Command Control
240
FQ2-S/CH User’s Manual
for Communications Settings
Response (Vision Sensor to PLC)
Batch Set D Terminal Status
Batch sets the ON/OFF status for the D terminals (D0 to D15).
Before executing this command, change the FQ2 execution mode to stop mode with the Set Execution Mode com-
mand.
Set Execution Mode: p.241
Command (PLC to Vision Sensor)
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1000 0000 0010 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0011 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
First word of com-
mand area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1000 0000 0011 0000 Command code
+3 0000 0000 0011 0000
+4 0000 0000 0000 0000 Terminal status (ON: 1, OFF: 0)
BIT0: D0
BIT1: D1
BIT2: D2
BIT3: D3
BIT4: D4
BIT5: D5
BIT6: D6
BIT7: D7
BIT8: D8
BIT9: D9
BIT10: D10
BIT11: D11
BIT12: D12
BIT13: D13
BIT14: D14
BIT15: D15
+5 0000 0000 0000 0000
Important
