Set Preprocessing Item Data for Image Adjustment
Sets parameters for a position compensation item or filter item.
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
Set Inspection Item Data
Sets parameters for the specified inspection item.
Command (PLC to Vision Sensor)
First word of com-
mand area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0001 0000 Command code
+3 0000 0000 0101 0000
+4 0000 0000 0000 0000 Position compensation item/filter item number
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Data number
+7 0000 0000 0000 0000
+8 0000 0000 0000 0000 Setting data
(1,000 times the value)
+9 0000 0000 0000 0000
First word of
response area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0001 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0101 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
First word of com-
mand area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0010 0000 Command code
+3 0000 0000 0101 0000
+4 0000 0000 0000 0000 Inspection item number
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Data number
+7 0000 0000 0000 0000
+8 0000 0000 0000 0000 Setting data
(1,000 times the value)
+9 0000 0000 0000 0000
