Command Control
234
FQ2-S/CH User’s Manual
for Communications Settings
Response (Vision Sensor to PLC)
Set Camera Parameter
Sets the value for the specified camera parameter.
Camera parameter numbers: p. 219
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
First word of
response area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0010 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0101 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
First word of com-
mand area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0100 0000 Command code
+3 0000 0000 0101 0000
+4 0000 0000 0000 0000 Camera parameter number
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Setting data
(1,000 times the value)
+7 0000 0000 0000 0000
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0100 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0101 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
