Omron FQ2-S Series User Manual

Command Control
236
FQ2-S/CH User’s Manual
for Communications Settings
Response (Vision Sensor to PLC)
Set Communication Input Status
This command sets the input status (allowed/prohibited) of the communications port for the specified
communications protocol.
Communications protocols with the input status set to prohibited will no longer receive communications after
being set as such.
However, for inputs related to hardware (parallel STEP signal and DSA signal), this setting is not applicable.
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0100 0000 0110 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0101 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
First word of com-
mand area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0111 0000 0001 0000 Command code
+3 0000 0000 0011 0000
+4 0000 0000 0000 0000 Communications protocol type to be set*
0: No protocol (TCP, UDP, FINS)
1: No protocol (RS-232C)
2: Parallel I/O
3: Fieldbus
5: PLC link
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Communications protocol status to be set
0: Input prohibited status
1: Input allowed status
+7 0000 0000 0000 0000
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0111 0000 0001 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0011 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
FQ2-S_CH_comm.book 236 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
