Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
237
5
Appendices
* The communications protocol types are defined by the following numbers.
Set Communication Output Status
This command sets the output status (allowed/prohibited) of the communications port for all the
communications protocol.
Communications protocols with the output status set to prohibited will no longer output signals after being set
as such.
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
Communica-
tions protocol
No.
Communications type Remarks
0 No protocol (Ethernet) No-protocol (UDP)
No-protocol (TCP)
1 No protocol (RS-232C)
2 Parallel I/O
3Fieldbus EtherNet/IP
PROFINET
4 Reserved Results in an error when specified.
5 PLC link PLC Link (SYSMAC)
PLC Link (MELSEC)
First word of com-
mand area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0111 0000 0010 0000 Command code
+3 0000 0000 0011 0000
+4 0000 0000 0000 0000 Communications protocol status to be set
0: Output prohibited status
1: Output allowed status
+5 0000 0000 0000 0000
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0111 0000 0010 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0011 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
