Command Control
244
FQ2-S/CH User’s Manual
for Communications Settings
Load System Data
TThis command loads system data that is stored on the SD card inserted in the Touch Finder.
The source for system data is the following fixed directory on the SD card.
\Sensor name\SYD
The file name is not case sensitive. The file name extension can be omitted.
Command (PLC to Vision Sensor)
*1 Loads the files named SensorSys_***.syd saved on the SD card. (***: Specified file number)
Response (Vision Sensor to PLC)
First word of com-
mand area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0011 0000 0000 0000 Command code
+3 0000 0000 0110 0000
+4 0000 0000 0000 0000 • EtherNet/IP,
PROFINET
File number to load
(0 to 999)*1
• PLC link
File name to load
64 characters max.
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000
---
: ::::
+35 0000 0000 0000 0000
First word of
response area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0011 0000 0000 0000 Command code
Response target command codes
+3 0000 0000 0110 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
