Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
227
5
Appendices
Acquire Statistical Data
Acquires the statistical data (such as the number of measurements, number of NG overall judgments, and
other information, since the power supply was turned ON) held by the Sensor.
The following types of statistical data are available. Specify the data to be read from these types with this
command.
•Number of measurements since the power supply was turned ON
•Number of OK overall judgments
•NG rate
•Number of NG judgments since the power supply was turned ON
•OK rate
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
Get Latest Error Information
Acquires the Sensor's most recent error code.
Command (PLC to Vision Sensor)
First word of com-
mand area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0110 0000 0001 0000 Command code
+3 0000 0000 0100 0000
+4 0000 0000 0000 0000 Type of statistical data to be acquired
1: Number of measurements
2: Number of NG judgments
3: NG rate
4: Number of OK judgments
5: OK rate
+5 0000 0000 0000 0000
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0110 0000 0001 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0100 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Value of acquired statistical data
The acquired value has been multiplied by
1,000.
+7 0000 0000 0000 0000
First word of com-
mand area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0101 0000 0000 0000 Command code
+3 0000 0000 0010 0000
FQ2-S_CH_comm.book 227 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
