Omron FQ2-S Series User Manual

Control and Output in No-Protocol (TCP) / No-Protocol (UDP)
178
FQ2-S/CH User’s Manual
for Communications Settings
Execution com-
mands
UPDATEREFITEM URI Re-registers the reference value for
the specified inspection item based
on the previously loaded image.
p.274
UPDATEREFPOS URP Re-registers the reference value for
the specified position compensation
item based on the previously loaded
image.
p.275
Commands to get
status
SCENE S Aquires the scene number currently
being used.
p.276
Commands to set
status
SCENE S Changes the scene number to be
used.
p.277
Commands to read
data
CAMDATA CD Acquires the value of the specified
camera parameter.
p.278
DICNOLIST DNL Acquires the list of registered dictio-
nary data numbers.
p.279
DIOFFSET DIO Acquires the terminal offset data
that is added to the IN0 to IN4 com-
mand parameters when executing
parallel commands.
p.280
DIPORTCOND DPC Batch acquires the ON/OFF status
for the IN terminals.
p.281
ERRGET None Acquires the Sensor's most recent
error code.
p.282
GETITEMFIG-
PARA M
GIFP Acquires the parameters for the
measurement region or model regis-
tration region set for an inspection
item.
p.283
GETPOSFIG-
PARA M
GPFP Acquires the parameters for the
measurement region or the model
registration region set for an image
adjustment item (filter item/position
compensation item).
p.286
GETDICFIGPARAM GDFP Acquires the specified dictionary
data cutout region parameters.
p.289
INPUTTRANS-
STATE
ITS Acquires the input status (allowed/
prohibited) for the communications
protocol set with the Set Communi-
cation Input Status command.
p.291
ITEMDATA ID Acquires parameters and measure-
ment values for the specified inspec-
tion item.
p.292
ITEMDATA2 ID2 Acquires the text string data of the
specified inspection item.
p.293
Type of command Command Abbreviation Function Reference
FQ2-S_CH_comm.book 178 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
