Control and Output in No-Protocol (TCP) / No-Protocol (UDP)
FQ2-S/CH User’s Manual
for Communications Settings
179
3
Controlling Operation and Outputting Data with an
Ethernet Connection
Commands to read
data
MODE None Acquires the FQ2 execution status
(execution mode).
p.294
OUTPUTTRANS-
STATE
OTS Acquires the output status (allowed/
prohibited) for the communications
protocol set with the Set Communi-
cation Output Status command.
p.295
PARAALLCOND PAC Batch acquires the ON/OFF status
for the all parallel I/O input terminals
other than the IN terminals.
p.296
Commands to Write
Data
PARAPORTCOND PPC Acquires the input signal ON/OFF
status for the specified parallel I/O
terminal.
p.297
POSITIONDATA PD Acquires data from a position com-
pensation item or filter item.
p.299
REGIMAGE RID Loads a registered image saved to
the SD card or PC Tool as the mea-
surement image.
p.300
SYSDATA SD Acquires the value set for the speci-
fied system data.
p.301
TOTALDATA TD Acquires the statistical data (such as
the number of measurements, num-
ber of NG overall judgments, and
other information, since the power
supply was turned ON) held by the
Sensor.
p.302
VERGET /S None Acquires the version information of
the Sensor software.
p.303
VERGET /H None Acquires the Sensor model. p.304
CAMDATA CD Sets the value for the specified cam-
era parameter.
p.305
DIOFFSET DIO Sets the value of the terminal offset
data that is added to the IN0 to IN4
command parameters
p.306
DOPORTCOND DPC Batch sets the ON/OFF status for
the D terminals (D0 to D15).
p.307
INPUTTRANS-
STATE
ITS Sets the input status (allowed/pro-
hibited) of the communications port
for the specified communications
protocol.
p.309
DICDELETE DD Deletes one character from the char-
acters registered in the model dictio-
nary.
p.310
DICREGIST DR Registers characters to the specified
dictionary data.
p.311
Type of command Command Abbreviation Function Reference
FQ2-S_CH_comm.book 179 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
