Omron FQ2-S Series User Manual

Command Control
306
FQ2-S/CH User’s Manual
for Communications Settings
DIOFFSET or DIO
Set Terminal Offset Data
This command sets the value of the terminal offset data that is added to the IN0 to IN4 command parameters
when executing parallel commands.
When using parallel command scene changing, you can change the scenes to change to by changing the Set
Terminal Offset Data value.
<Command Format>
<Response Format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
Terminal offset value Specifies the value to be added to the IN0 to IN4 command parameters when executing
parallel commands.
When using the Sensor in Expanded Mode while using the standard parallel interface of
the Sensor, the range of scene numbers that can be changed to with scene changing is
limited to 0 through 15. By offsetting the command parameter, the scene can be changed
to scene number 0 through 31.
Terminal offset value
(4 digits max.)
Terminal offset value
(4 digits max.)
Space
(0x20)
Space
(0x20)
DI FSET CR O
DIO
F
Command
Delimiter
Delimiter
Command
or
CR
Delimiter
CR OK
CR ER
Delimiter
