Omron FQ2-S Series User Manual

Control and Output in No-Protocol (TCP) / No-Protocol (UDP)
180
FQ2-S/CH User’s Manual
for Communications Settings
Commands to Write
Data
SETITEMFIG-
PARA M
SIFP Changes the range set as the mea-
surement region or the model regis-
tration region for an inspection item.
p.312
SETPOSFIG-
PARA M
SPFP Changes the range set as the mea-
surement region or the model regis-
tration region for an image
adjustment item (filter item/position
compensation item).
p.314
SETDICFIGPARAM SDFP Sets the specified dictionary data
cutout region parameters.
p.317
ITEMDATA ID Sets parameters for the specified
inspection item.
p.319
ITEMDATA2 ID2 Sets the text string data for the spec-
ified inspection item.
p.320
MODE None Sets the FQ2 execution status (exe-
cution mode).
p.321
OUTPUTTRANS-
STATE
OTS Sets the output status (allowed/pro-
hibited) for the specified communi-
cations protocol.
p.322
PARAALLCOND PAC Batch sets the ON/OFF status for
the all parallel I/O output terminals
other than the D terminals (D0 to
D15).
p.323
PARAPORTCOND PPC Sets the input signal ON/OFF status
for the specified parallel I/O terminal.
p.325
POSITIONDATA PD Sets parameters for a position com-
pensation item or filter item.
p.327
SYSDATA SD Sets the value to the specified sys-
tem data.
p.328
Load setting data
commands
SCNLOAD None Loads scene data that is stored on
the SD card inserted in the Touch
Finder.
p.329
SGRLOAD None Loads all scene data that is stored
on the SD card inserted in the Touch
Finder.
p.330
SYSLOAD None Loads system data that is stored on
the SD card inserted in the Touch
Finder.
p.331
BKDLOAD None Loads all setting data (all scene
data, system data, calibration group
data) for the Sensor saved as a
backup file from the SD card
inserted in the Touch Finder.
p.332
Type of command Command Abbreviation Function Reference
FQ2-S_CH_comm.book 180 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
