MODE
Set Execution Mode
Sets the FQ2 execution status (execution mode).
<Command Format>
<Response Format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
* The execution mode is classified into the following modes depending on the FQ2 execution status.
• Run mode: The mode to run actual measurements. I/O is possible with external devices such as a PLC.
• Stop mode: This mode is for monitoring/controlling the output status of the parallel signals through communication commands only.
Therefore, I/O that is unrelated to parallel terminal control is not possible.
• Input: Parallel signal input is not possible. Command input is not possible. (However, the terminal status monitor, set-
ting commands can be used)
• Output: Parallel signal output is possible. Data output is not possible.
When using commands (Set Terminal Status/Batch Set Terminal Status/Batch Set DO Status) to control the ON/
OFF status of the parallel I/O terminals with communication commands, change the FQ2 to stop mode with this
command.
Execution mode Specifies the FQ2 execution mode
*
to be set.
1: Run mode
2: Stop mode
Note
Space
(0x20)
Execution mode
(1 digit max.)
MO CR DE
Command
Delimiter
Delimiter
CR OK
CR ER
Delimiter
