Command Control
320
FQ2-S/CH User’s Manual
for Communications Settings
ITEMDATA2 Command or ID2
Set Inspection Item Text String Data
This command sets the text string data for the specified inspection item.
<Command Format>
<Response Format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
Inspection item number Specifies the inspection item number. (0 to 31)
External reference data
number
Specifies the external reference data number.
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
Text string data Specifies the text string data for the specified inspection item.
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
IT DATA2
Text
string data
CR EM
Inspection
item number
(2 digits max.)
External reference
data number
(4 digits max.)
Command
Space
(0×20)
Space
(0×20)
Space
(0×20)
Delimiter
Text
string data
DelimiterCommand
or
D 2I
Inspection item
number
(2 digits max.)
External reference
data number
(4 digits max.)
CR
Space
(0×20)
Space
(0×20)
Space
(0×20)
CR OK
Delimiter
CR ER
Delimiter
