Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
319
5
Appendices
ITEMDATA Command or ID
Set Inspection Item Data
This command sets the parameters of the specified inspection item.
<Command Format>
<Response Format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
Inspection item number Specifies the inspection item number. (0 to 31)
External reference data
number
Specifies the external reference data number. (0 to 9999)
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
Setting value Specifies the setting value.
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
IT DATA
Setting
value
Setting
value
CR EM
Inspection
item number
(2 digits max.)
Command
Space
(0x20)
Space
(0x20)
Space
(0x20)
Delimiter
Delimiter
External reference
data number
(4 digits max.)
External reference
data number
(4 digits max.)
Command
or
DI CR
Space
(0x20)
Space
(0x20)
Space
(0x20)
Inspection item
number
(2 digits max.)
CR OK
Delimiter
CR ER
Delimiter
