Omron FQ2-S Series User Manual

Control and Output in No-Protocol (TCP) / No-Protocol (UDP)
FQ2-S/CH User’s Manual
for Communications Settings
181
3
Controlling Operation and Outputting Data with an
Ethernet Connection
Load setting data
commands
CLBLOAD None Loads calibration data that is stored
on the SD card inserted in the Touch
Finder as the data for the specified
calibration number.
p.333
CGRLOAD None Loads all calibration data that is
stored on the SD card inserted in the
Touch Finder.
p.334
DICLOAD None Loads model dictionary data that is
stored on the SD card inserted in the
Touch Finder as the model dictio-
nary with the specified number.
p.335
DGRLOAD None Loads all model dictionary data that
is stored on the SD card inserted in
the Touch Finder.
p.336
Save setting data
commands
SCNSAVE None Saves scene data to the SD card
inserted in the Touch Finder as a file.
p.337
SGRSAVE None Saves all scene data as a file to the
SD card inserted in the Touch
Finder.
p.338
SYSSAVE None Saves system data as a file to the
SD card inserted in the Touch
Finder.
p.339
IMAGESAVE None Saves image data saved in the Sen-
sor’s memory by the logging function
to the SD card inserted in the Touch
Finder as ifz data.
p.340
ALLIMAGESAVE AIS Saves all image data saved in the
Sensor’s memory by the logging
function to the SD card inserted in
the Touch Finder as ifz data.
p.341
BKDSAVE None Saves all setting data (all scene
data, system data, calibration group
data) for the Sensor to the SD card
inserted in the Touch Finder as a
backup file.
p.342
CLBSAVE None Saves the calibration data with the
specified calibration number as a file
to the SD card inserted in the Touch
Finder.
p.343
CGRSAVE None Saves all calibration data as a file to
the SD card inserted in the Touch
Finder.
p.343
DICSAVE None Saves model dictionary data as a file
to the SD card inserted in the Touch
Finder.
p.344
DGRSAVE None Saves all model dictionary data as a
file to the SD card inserted in the
Touch Finder.
p.345
Type of command Command Abbreviation Function Reference
