CLBLOAD
This command loads calibration data that is stored on the SD card inserted in the Touch Finder as the data for
the specified calibration number.
The source for calibration data is the following fixed directory on the SD card.
\Sensor name\CLB
<Command Format>
<Response Format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
Do not turn off power to the Vision Sensor until there is a response.
Calibration number Specifies the calibration data number you want to load (0 to 31)
Calibration data file
name
Specifies the calibration data file name you want to load. (64 characters max.)
The file name extension (.clb) can be omitted.
CLBLOAD
Space (0x20)Space (0x20)
C
R
Calibration data file name
Calibration data number (2 digits max.)
Delimiter
CR
OK
CR
ER
Delimiter
