Omron FQ2-S Series User Manual

Command Control
292
FQ2-S/CH User’s Manual
for Communications Settings
ITEMDATA or ID
Acquire Inspection Item Data
This command acquires the parameters of the specified inspection item.
<Command Format>
<Response Format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
Inspection item number Specifies the inspection item number. (0 to 31)
External reference data
number
Specifies the external reference data number. (0 to 9999)
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
Acquired value Returns the data for the specified inspection item.
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
I T D A T A
CR
E M
Inspection item number
(2 digits max.)
Command
Space
(0x20)
Space
(0x20)
Delimiter
Command
or
D I CR
Delimiter
Space
(0x20)
Space
(0x20)
External reference
data number
(4 digits max.)
Inspection item
number
(2 digits max.)
External reference
data number
(4 digits max.)
CR
Acquired
value
Delimiter
CR OK
CR ER
Delimiter
