INPUTTRANSSTATE or ITS
Acquire Communication Input Status
This command acquires the input status (allowed/prohibited) for the communications protocol set with the Set
Communication Input Status command.
<Command Format>
<Response Format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
Communications protocol
type to be acquired
Specifies the communications protocol type to be acquired.
0: No protocol (TCP, UDP, FINS)
1: No protocol (RS-232C)
2: Parallel I/O
3: Fieldbus
5: PLC link
Acquired value Returns the acquired communications protocol status.
0: Input prohibited status
1: Input allowed status
I N TTRA CR P
S
U N TATESS
Communications protocol type to be acquired
(1 digit max.)
Communications protocol type to be acquired
(1 digit max.)
Command
Space
(0x20)
Delimiter
Delimiter
Command
or
TI CR
Space
(0x20)
CR
Acquired
value
Delimiter
CR OK
CR ER
Delimiter
