FQ2-S/CH User’s Manual
for Communications Settings
* The dictionary data cutout region figure parameters are the upper-left coordinates and the lower-right coordinates of the rectangle.
Name Data type Upper/lower limit value
Parameter 1 Figure types Integer type With the FQ2, fixed value of 8.
Parameter 2 Rectangle upper-left X
coordinate
Parameter 3 Rectangle upper-left Y
coordinate
Parameter 4 Rectangle lower-right X
coordinate
Parameter 5 Rectangle lower-right Y
coordinate
