Control and Output in No-Protocol (TCP) / No-Protocol (UDP)
FQ2-S/CH User’s Manual
for Communications Settings
177
3
Controlling Operation and Outputting Data with an
Ethernet Connection
Format of no-protocol (UDP) commands
Delimiters are not necessary in commands used in no-protocol (UDP) communication.
Delimiters are also not used in responses. In cases such as a Get Scene Number command where the
acquired data is followed by an OK response, the acquired data and OK are sent in separate packets.
Command List (No-protocol (TCP), No-protocol (UDP))
The following table lists the no-protocol commands.
Commands that can be used in no-protocol Ethernet communications are listed below.
Type of command Command Abbreviation Function Reference
Execution com-
mands
CLRERR None Clears the error output status (error
output and error indicator).
p.263
CLRMEAS None Clears the measurement values. p.263
CLRTOTAL CTD Clears the statistical data p.264
DATASAVE None Saves the current setting data (sys-
tem data, scene groups, and calibra-
tion data) in the Sensor.
p.264
ECHO EEC Returns any data (32 bits or 2
words) sent by the external device
as-is.
p.265
ITEMTEACH IT Updates the reference data for the
specified inspection item.
p.265
MEASURE M Executes one measurement. p.268
MEASURE /C M /C Starts continuous measurements. p.266
MEASURE /E M /E Ends continuous measurements. p.267
MODEL None Re-registers the models for regis-
tered Search, Shape search II, Sen-
sitive search, and Color data
inspection items.
p.269
POSITIONTEACH PT Updates reference data for the spec-
ified image adjustment processing
item (filter item/position compensa-
tion item).
p.270
REGIMAGE RID Sets the latest image or a specified
logging image as a registered
image.
p.271
RESET None Restarts the Sensor. p.272
TEACH None Executes teaching for all registered
items.
p.272
TIMER TMR Executes the specified command
after the specified waiting time
elapses.
p.273
