Omron FQ2-S Series User Manual

Outputting Data and Controlling Operation through PROFINET
158
FQ2-S/CH User’s Manual
for Communications Settings
● Commands to Read Data
Command code in
command area (hex)
Command name Function Reference
00401010 Get Image Adjustment Item
Data
acquires parameters and measurement val-
ues for a position compensation item or filter
item.
p.217
00401020 Get Inspection Item Data Acquires parameters and measurement val-
ues for the specified inspection item.
p.218
00401040 Acquire Camera Parameter Acquires the value of the specified camera
parameter.
p.218
00403000 Get Software Version Informa-
tion
Acquires the Sensor's software version. p.221
00404010 Acquire System Data Acquires the value set for the specified sys-
tem data.
p.222
00404060 Acquire Terminal Offset Data Acquires the terminal offset data that is
added to the IN0 to IN4 command parame-
ters when executing parallel commands.
p.226
00406010 Acquire Statistical Data Acquires the statistical data (such as the
number of measurements, number of NG
overall judgments, and other information,
since the power supply was turned ON) held
by the Sensor.
p.227
00205000 Get Latest Error Information Acquires the latest error information from the
Sensor.
p.227
00207010 Acquire Communication Input
Status
Acquires the input status (allowed/prohib-
ited) for the communications protocol set with
the Set Communication Input Status com-
mand.
p.228
00207020 Acquire Communication Out-
put Status
Acquires the output status (allowed/prohib-
ited) for the communications protocol set with
the Set Communication Output Status com-
mand.
p.229
00208010 Acquire Terminal Status Acquires the ON/OFF status of the input sig-
nal for the specified parallel I/O terminal.
p.230
00208020 Batch Acquire Terminal Status Batch acquires the ON/OFF status for the all
parallel I/O input terminals other than the IN
terminals.
p.231
00208030 Batch Acquire IN Terminal Sta-
tus
Batch acquires the ON/OFF status for the IN
terminals.
p.231
0020F000 Acquire Execution Mode Acquires the FQ2 execution status (execution
mode).
p.232
