Outputting Data and Controlling Operation through PROFINET
FQ2-S/CH User’s Manual
for Communications Settings
159
3
Controlling Operation and Outputting Data with an
Ethernet Connection
● Commands to Write Data
● Load Setting Data Commands
Command code in
command area (hex)
Command name Function Reference
00501010 Set Image Adjustment Item
Data
Sets parameters for a position compensation
item or filter item.
p.233
00501020 Set Inspection Item Data Sets parameters for the specified inspection
item.
p.233
00501040 Set Camera Parameter Sets the value for the specified camera
parameter.
p.234
00504010 Set System Data Sets the value to the specified system data. p.235
00504060 Terminal Offset Data This command sets the value of the terminal
offset data that is added to the IN0 to IN4
command parameters
p.235
00307010 Set Communication Input Sta-
tus
This command sets the input status (allowed/
prohibited) of the communications port for the
specified communications protocol.
p.236
00307020 Set Communication Output
Status
This command sets the output status
(allowed/prohibited) of the communications
port for the specified communications proto-
col.
p.237
00308010 Set Terminal Status This command sets the output signal ON/
OFF status for the specified parallel I/O termi-
nal.
p.238
00308020 Batch Set Terminal Status Batch sets the ON/OFF status for the all par-
allel I/O output terminals other than the D ter-
minals (D0 to D15).
p.239
00308030 Batch Set D Terminal Status Batch sets the ON/OFF status for the D termi-
nals (D0 to D15).
p.240
0020F000 Set Execution Mode Sets the FQ2 execution status (execution
mode).
p.241
Command code in
command area (hex)
Command name Function Reference
00601000 Load Scene Data Loads scene data that is stored on the SD
card inserted in the Touch Finder.
p.242
00602000 Load All Scene Data Loads all scene data that is stored on the SD
card inserted in the Touch Finder.
p.243
00603000 Load System Data This command loads system data that is
stored on the SD card inserted in the Touch
Finder.
p.244
00605000 Load All Setting Data This command loads all setting data (all
scene data, system data, calibration group
data) for the Sensor saved as a backup file
from the SD card inserted in the Touch
Finder.
p.245
0060A000 Load Calibration Data This command loads calibration data that is
stored on the SD card inserted in the Touch
Finder as the specified calibration number.
p.246
