Outputting Data and Controlling Operation through PROFINET
156
FQ2-S/CH User’s Manual
for Communications Settings
Commands (PROFINET)
This section describes the PROFINET commands.
The command codes of the commands are assigned to external device memory in the order below.
Example: Start continuous measurements command “00101020”
● Execution Commands
+268 Output data 64 Output data 63 (32 bits)
+269
+270
+271
Signal Signal name Function Application
DATA0-63 Output data 0 to 63 These I/O ports output the output data that is
specified for the data output method.
The data that can be output is determined by
the set value of the Output data size setting as
follows:
32 bytes: Output data 0 to 7
64 bytes: Output data 0 to 15
128 bytes: Output data 0 to 31
256 bytes: Output data 0 to 63
Command/
response commu-
nications
Output Area
(command
area)
Command code
(HEX)
Bits
7 6 5 4 3 2 1 0
+4 20 00100000
+5 10 00010000
+6 10 00010000
+7 00 00000000
Command code in
command area (hex)
Command name Function Reference
00101020 Start Continuous Measure-
ments
Starts continuous measurements. p.207
00101030 End Continuous Measure-
ments
Ends continuous measurements. p.208
00102010 Clear Measurement Values Clears the measurement values. p.208
00102020 Clear Data Output Buffer Clears all data in the data output buffer of the
Sensor.
p.209
00102060 Clear Statistical Data Clears the statistical data (such as the num-
ber of measurements, the number of NG
overall judgments, the NG rate, and other
information since the power supply was
turned ON) produced by the logging function
held by the Sensor.
p.209
Input Area
(Output Area)
Bits Description
7 6 5 4 3 2 1 0
