Omron FQ2-S Series User Manual

Controlling Operation and Outputting Data with EtherNet/IP Communications
100
FQ2-S/CH User’s Manual
for Communications Settings
Output Results
The expression that is registered for data 0 assigns the data for 16 items (64 bytes) in the output area as shown
below.
Setting the Output Format
[In/Out] − [I/O setting] − [Output data setting] − [Link data output/Fieldbus data output]
1 Press [Output format].
2 Press [Output form].
3 Set either a floating point decimal or a fixed decimal for the output form.
Output area data Assigned data
Output data 0 (4 bytes) I0.X[0] (Position X 1st point)
Output data 1 (4 bytes) I0.Y[0] (Position Y 1st point)
Output data 2 (4 bytes) I0.SX[0] (Reference SX 1st point)
Output data 3 (4 bytes) I0.SY[0] (Reference SY 1st point)
Output data 4 (4 bytes) I0.X[1] (Position X 2nd point)
Output data 5 (4 bytes) I0.Y[1] (Position Y 2nd point)
Output data 6 (4 bytes) I0.SX[1] (Reference SX 2nd point)
Output data 7 (4 bytes) I0.SY[1] (Reference SY 2nd point)
Output data 8 (4 bytes) I0.X[2] (Position X 3rd point)
Output data 9 (4 bytes) I0.Y[2] (Position Y 3rd point)
Output data 10 (4 bytes) I0.SX[2] (Reference SX 3rd point)
Output data 11 (4 bytes) I0.SY[2] (Reference SY 3rd point)
Output data 12 (4 bytes) I0.X[3] (Position X 4th point)
Output data 13 (4 bytes) I0.Y[3] (Position Y 4th point)
Output data 14 (4 bytes) I0.SX[3] (Reference SX 4th point)
Output data 15 (4 bytes) I0.SY[3] (Reference SY 4th point)
• The inspection results will be output according to the sorting method that is set for multi-point output for the
inspection item.
• In order to output multiple detection results of the inspection items that can be output their results simultaneously,
from the [Inspection] menu of the targeted inspection item, press [Multi-point output] and select [Yes].
Item Description Setting range
Output form
Set the output form for numerical data.
Fixed decimal point
Outputs the data as a x1000 value.
Example: 123.456 is output as 0x0001E240
Floating decimal point
Outputs the data in floating point decimal format.
Example: −123.4567 is output as 0xc2f6e979
Floating point or fixed point (default: Floating
point)
Note
▲
